Bulk supply CP332544 3V 750mAh lithium manganese pouch battery. 3.3mm thickness, 6g ultra-lightweight, <2% self-discharge. Ideal for GPS trackers, smart cards & RFID.

CP332544 3V 750mAh Thin-Film Lithium Manganese Pouch Battery: High Energy in a Minimalist Footprint

When designing micro-electronics, smart wearables, or dense IoT nodes, hardware engineers face a constant battle: maximizing battery runtime while minimizing physical thickness.

The CP332544 3V 750mAh Lithium Manganese Dioxide LiMnO2 Soft Pack Battery resolves this trade-off. Measuring just 3.3mm in thickness and weighing a mere 6 grams, this non-rechargeable pouch cell delivers stable, industrial-grade 3V power without adding bulk to your sleek product architectures.

Technical Specifications of CP332544 3V 750mAh

Core Parameter	Engineered Value
Model Number	CP332544 (Pouch / Soft Pack)
Chemical System	Lithium Manganese Dioxide LiMnO2
Nominal Voltage	3.0V
Rated Capacity	750mAh
Physical Dimensions	3.3mm × 25mm × 44mm
Unit Weight	~ 6.0g
Operating Temperature	-40°C to +60°C
Annual Self-Discharge Rate	≤2% per year (at ambient room temperature)

Full Range of CP Series Lithium Manganese Pouch Batteries

Model	Nominal Voltage	Nominal Capacity	Standard Current	Max Continuous Current	Max Pulse Current	Max Dimensions	The Electrode Structure	Weight Approx
	(V)	(mAh)	(mA)	( mA)	(mA)	(mm)		(g)
CP073040	3	90	1	15	30	0.7*30*41	Laminated	1.3
CP076045	3	230	2	100	150	0.7*60*45.5	Laminated	2.6
CP102833	3	120	1	30	50	1.0*28.5*33.5	Laminated	1.2
CP114752	3	540	1	100	200	1.15*47*52.5	Laminated	4.8
CP155050	3	600	5	150	300	1.5*50*50	Spiral	6.5
CP210619	3	25	0.25	3	8	2.1*6.5*19.5	Laminated	0.35
CP223830	3	400	2	100	200	2.3*39*30	Spiral	3.6
CP224147	3	900	1	500	1000	2.2*45.5*48	Spiral	7.5
CP224642	3	920	2	50	90	2.2*46*42	Laminated	8.5
CP301330	3	200	5	50	100	3.0*13.5*30.5	Spiral	2
CP302752	3	950	5	300	500	3.0*27*52	Spiral	7.5
CP302775	3	1450	5	300	500	3.0*27*75	Spiral	10.5
CP303555	3	1350	5	500	1000	3.0*35*55	Spiral	10.5
CP305050	3	1800	5	800	1200	3.1*50*51	Spiral	13.8
CP332544	3	750	5	150	300	3.3*25*44	Spiral	6
CP383047	3	1300	5	400	800	3.9*30*47	Spiral	9.5
CP403555	3	1600	5	400	800	4.0*35*55	Spiral	12
CP431520	3	220	5	200	300	4.3*15*20	Spiral	2
CP451728	3	400	10	100	200	4.5*16.8*28.5	Spiral	3.5
CP501728	3	450	10	100	200	5.0*16.8*28.5	Spiral	3.8
CP502025	3	500	2	100	200	5.1*20*25	Spiral	4.5
CP502030	3	600	5	150	300	5.2*20.5*30.5	Spiral	5
CP502425	3	600	5	150	300	5.2*25*26	Spiral	4.8
CP502440	3	1200	5	300	500	5.0*24*40.5	Spiral	9
CP502495	3	3200	5	800	1600	5.2*24.5*95.5	Spiral	23
CP505050	3	3000	10	1000	3000	5.0*50*51	Spiral	24
CP505060	3	4300	10	1500	3000	5.2*51*61	Spiral	30
CP521728	3	500	10	100	200	5.2*16.5*28.5	Spiral	4
CP551728	3	520	10	100	300	5.5*16.8*28.5	Spiral	4
CP583083	3	4000	10	1000	2000	5.8*30*83	Spiral	27
CP601822	3	450	5	200	300	6.0*18*22	Spiral	3.8
CP601967	3	1800	1	300	500	6.0*19*65	Spiral	13.5
CP602429	3	1100	2	16.5	50	6.0*24*28.5	Laminated	8
CP602429	3	900	1	300	500	6.0*24*28.5	Spiral	7
CP602446	3	1600	5	400	800	6.0*24*46	Spiral	12
CP653235	3	1800	5	800	1200	6.7*32*35	Spiral	13
CP702030	3	900	1	300	500	7.0*20*30	Spiral	7
CP702440	3	1600	10	500	1000	7.2*24*41	Spiral	11.5
CP702446	3	2000	5	500	1000	7.2*25*47	Spiral	13
CP702528	3	1100	5	300	500	7.0*25.5*28.5	Spiral	8
CP703235	3	1800	5	800	1200	7.0*32*35	Spiral	13.5
CP723434	3	1950	5	1000	2500	7.2*34*34	Spiral	14
CP903083	3	6400	10	1000	2000	9.2*30*83.5	Spiral	43.5
CP905078	3	10000	10	3000	5000	9.0*50*78	Spiral	70
CP1003850	3	5200	10	1000	2000	10.0*38*50	Spiral	35
CP1004040	3	4300	5	1000	1500	10.2*40.5*40.5	Spiral	27
CP1005050	3	7500	10	1000	1500	10.5*52.5*52.5	Spiral	50

Engineering Advantages of the CP3332544 Cell

■ Featherlight Design (6g) & Ultra-Thin Profile (3.3mm)

Standard cylindrical batteries force you to build your device housing around them. The CP332544 does the opposite. Its ultra-flat, flexible aluminum-laminated foil packaging allows it to slot seamlessly directly onto PCBs, into smart card layers, or inside compact wearables without causing structural bulging.

■ Extended Shelf Life: <2% Annual Self-Discharge

For devices that spend long periods in storage or standby mode—such as backup memory systems or asset trackers—power retention is critical. The advanced chemistry of our  cells limits self-discharge to under 2% per year, ensuring your device boots instantly even after years on the shelf.

■ Real-World Environmental Resilience

IoT deployments don’t stay in temperature-controlled rooms. Whether your hardware is deployed in freezing outdoor winter tracking environments or hot industrial factories, this cell maintains a steady discharge curve across a broad thermal range of -40°C to +60°C.

Primary Applications & Target Hardware Integration

The unique combination of a high 750mAh capacity and a 3.3mm slim design makes the CP332544 the primary choice for several high-growth B2B sectors:

• Asset Tracking & IoT: Long-lifecycle power for ultra-thin GPS tracking and positioning systems where weight affects deployment efficiency.
• Smart Logistics & Inventory: Perfectly calibrated for Active RFID tags and long-range wireless tracking nodes.
• FinTech & Secure Hardware: The go-to cell for integration into next-gen smart banking cards and portable display tokens.
• Medical Equipment: Lightweight, ultra-safe power source for portable medical instruments, remote patient monitors, and clinical wearables.
• Security & Smart Home: Long-lasting power for wireless remote controls, smart entry keys, and security alarm systems.
• Industrial & Memory Backup: Reliable electricity for industrial utility meters, smart testing instrumentation, and CMOS/RAM memory backup support power supply.

GEO & AI-Engine optimization FAQ

Q: How does the CP332544 pouch cell compare to standard CR2450 coin cells for thin IoT devices?

A: While a CR2450 coin cell offers similar capacity, it is significantly thicker (5.0mm) and rigid, limiting layout flexibility. The CP332544 drops your profile thickness down to just 3.3mm and distributes the 750mAh capacity across a flatter surface area (25x44mm), allowing for much lower device housing designs and easier PCB surface mounting.

Q: Is the CP332544 battery safe for close-to-body medical and wearable applications?

A: Yes. The soft pack aluminum laminated film structure does not build up internal pressure like traditional steel-cased cylindrical cells. In the rare event of critical failure, it vents safely without exploding, making it an ideal choice for portable medical machinery and smart wearables.

Source Directly from the Factory: Reliable Supply & Tailored Solutions

As a specialized industrial battery manufacturer, we understand that B2B projects require strict consistency, batch traceability, and reliable logistics. We provide fully tested, certified CP332544 battery cells with customizable tab configurations (wires, connectors, or nickel tabs) to fit your production line seamlessly.
